Description

Deck plate: 14 mm
Bottom plate: 12 mm
Side shell: 12 mm
Longitudinal BHD: 9 mm
Transverse BHD: 9 mm
Deck longitudinal: L125×75×9
Bottom longitudinal: L125×75×10
Side longitudinal: L125×75×7
Side frame: L150×90×10
Long. BHD longitudinal: L125×75×7
Transverse BHD stiffener: L125×75×7
Deck transverse: FLG 450×10/150
Deck girder: FLG 450×10/150
Bottom transverse: FLG 450×10/150
Bottom girder: FLG 450×10/150
Side web frame: FLG 470×10/150 & FLG 470×12/150
Long. BHD web: FLG 450×10/150
Stanchion: H200×200×8/12
Diagonals: FLG 160×160×10 & FLG 200×200×12
Bilge chine: F50 round bar
LOA 94,5 m
Beam 27,45 m
Draft 4,8 m

Built in year 2025
Class : Bureau Veritas

Deadweight : 10.000 metric tonnes

Specifications

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
