Located: Singapore / ready for Shipment L TYPE OF CRANE DKW 2000 Offshore Wire Luffing Electro Hydraulic Pedestal Crane PRIME MOVER Electro-Hydraulic ENVIRONMENT High humidity DESIGN TEMPERATURE Design temp -10°C - +40°C. Crane design temperature is in accordance with class requirements for worldwide service. AREA CLASSIFICATION Crane designed for Safe Zone. Electrical equipment on boom tip designed for Hazardous Area – Zone 2 IIA T3 CERTIFICATION - Makers Certificate. - ABS Certificate for complete crane. - API monogram. - INMETRO for Explosion proof electrical components FEM CLASSIFICATI... read more

1 KNB installed with a max lifting capacity of 9 tons... read more

Located Singpaore / ready to be shipped. TYPE OF CRANE DKF 2000 Offshore Knuckle Boom Electro Hydraulic Pedestal Crane PRIME MOVER Electro-Hydraulic ENVIRONMENT High humidity DESIGN TEMPERATURE Design temp -10°C - +40°C. Crane design temperature is in accordance with class requirements for worldwide service. AREA CLASSIFICATION Crane designed for Safe Zone. Electrical equipment on Knuckle jib and hooks: Zone 2 IIA T3. Electrical equipment on Main boom, outer half: Zone 2 IIA T3. CERTIFICATION - Makers Certificate. - ABS Certificate for complete crane. - API monogram. - INMETRO for Explosio... read more

4 x 40T HND Winches fitted with 28m x 24mm wire rope - These were purchase new in 2023 for an accommodation barge project with minimal use and are now available for prompt sale basis delivery in Hartlepool, UK... read more

FRC SPEC Length overall 12.2 metres Length hull 12.2 metres Beam (Moulded) 4.5 metres Draft loaded 0.7 meters Lightship displacement Approximately 12 tons Tank Capacities Fuel Oil 1,800 litres Crew 1 Passenger 10 Machinery Main Propulsion Engines 2 x Cummins QSB-6.7 312kW (419bhp ) @ 3000rpm or equal Propulsion 2 x NAMJET TJ431HH Water Jets Performance The vessel shall be capable of achieving the following performance in calm water (up to sea state 2): Speed 22 knots @ 100% MCR - based on 2.5 Dead Weight Tonnes (DWT) Bollard Pull 3.5 tons DESIGN OPERATING CONDITIONS Engineering systems sh... read more

LOA 23.4 m... read more

170 ton at first layer, speed 0 –20 m/min 60 ton at last layer, speed 0 –40 m/min Capacity: 1800m 8” rope or 7000m 3”steel wire Water cooled brake resistors Wire/Rope spooling device Motor Control and local Control Panel (radio) Remote Control Console Low voltage VFD Single drive system Recommended spare parts for five year operation HPU Electric motors: 2 x ABB/Siemens/ Franz Wolfer/VEM 350KW per unit, heater build-in motor IP56, S1 continuous duty, insulation class F Electrical general: Ambient temp. 50 deg C Voltage440V/660V, frequency60Hz Winch Band Brake: Hydraulic set on drum fla... read more

Three degrees of freedom on the MCG are actively compensated by the control system: - Slewing Drives attached to the Gangway Slewing Bearing generate slewing motion relative to the Cursor. Slewing drives in interaction with the slewing ring provide safe and efficient slewing motion of the gangway. - Luffing Four hydraulic cylinders attached between the King and the Bridge provide gangway luffing motion. Two of the cylinders, one on each side, are powered by pre-charged accumulators, and supporting the gangway self-weight. The two other cylinders are used to actively generate luffing moti... read more

The 6-point mooring line system can be installed easily to any Vessel. It works as a single unit and it includes, one bridge control system, 6x 35 ton Pull / 90 ton Brake – high capacity Drum Mooring winches, which are working with 3x Hydraulic power packs. LOA 2.95 m... read more

Crane type : HSC 240-200/80/30-10/25/27 Offshore Internal lift : 20T / 8T / 3T Internal max. outreach : 10m / 25m / 27m Internal min. outreach : 2,5m / 4,8m / 5,2m External lift : 8,5T / 3,5T / 3T External max. outreach : 10m / 25m / 27m Internal min. outreach : 2,5m / 4,8m / 5,2m Max. load for Lifting of Personal (internal & external) : 3T Offshore lifting capacities see “Load chart with dynamic factors”. Hoisting speed full load : 0-42 m/min. for 20T / 8,5T : 0-21 m/min. for 8T / 3,5 T : 0-30 m/min. for 3T(with basket) Luffing time up : 80 sec. Luffing time down : 80 sec. Slewing speed :... read more

The Access & Cargo Tower is a combined gangway and elevator for the handling of personnel and cargo from the warehouse to the wind turbine. The Elevator, tower and gangway is designed to ensure safe and efficient transfer of personnel and goods to the offshore wind turbines or offshore platforms. The system is an integrated system for step-less transfer of personnel and cargo from multiple deck levels up to the turbine platform. To assure comfortable crossing and maximum workability the height of the access bridge can be adjusted to the landing height of the platform. The integrated elevator ... read more

Maker NOV/Am-Clyde / Model ATL-60 Build 2012, New boom 2020 Class DNV incl. man riding Crane Voltage 690V, Crane equipped with 6,6 KV transformers Crane Capacities Capacity Main 1200t @ 21-25 m, 750t @ 50 m, 160t @ 100 m Capacity Whip 50 t @ 23-125 m Man-riding capacity 5 ton all radii Boom Length (from center line of boom foot pin) Length to main fall upper block sheaves: 115 m Length to whip fall jib tip sheaves: 120.0 m Operating Radius Main fall: 21.0–121.0 m Whip fall: 23.1–126 m Main hoist winch 66.8 MT single linepull at 64 m/ min, 4 x 186 KW Whip hoist winch 27.5 MT single lin... read more

The above is part of a complete list of equipment for 2 VESSELS - UT 786 CD AHTS / DESIGN - available at GRS - pls contact us also for the complete Equipment Spread! - ROLLS ROYCE TIER III MAIN ENGINES & GENERATORS - CPP PROPELLERs AND PROPELLER SHAFT - STERN AND BOW THRUSTERS AND AZIMUTH THRUSTERs - WINCH PACKAGE INCL TUGGERS WINCHES, TOW PINS, SHARK JAWS, STERNROLLER - CARGO RAIL CRANES - BULK HANDLING SYSTEM - DESIGN DRAWINGS Equipment will include 12 months warranty from manufacturer. Equipment was delivered 2012 and is for sale at approx 50 % of new build value. Located South East Asia.... read more

LOA 8.1 m Beam 5 m Built in year 2015... read more

MANITOWOC 4000 RINGER. 230 TONNE. 220 FOOT BOOM. MAJOR REFURBISHMENT AND UPGRADE 2016. 36 FOOT RINGER.... read more

The Modular Saturation Diving System is designed for operations up to 305 MSW (1,000 ft) and offers versatile configurations tailored to operational requirements. Built in compliance with DNV Class Certificate, IMCA design standards, IMO, and SOLAS regulations, the system accommodates up to 12 divers across two 6-man twin-lock chambers. For optimized deck space, the system can be reconfigured to operate with a single 6-man twin-lock chamber. The system integrates a 12-man Hyperbaric Rescue Chamber (HRC), certified by DNV, which can decompress up to 4 divers. The HRC is deployable on either si... read more

For charter/ lease – completely ready for mobilization/ subsea saturation projects globally with up to date IMCA/ Class Certifications upon request. This modular sat diving system can be installed on board of chartered Vessel and dedicated sat/ air diving team is ready to serve any subsea project worldwide upon request. Owners require LOI from Ship Owners or end Client further projects mobilization. The JRM SAT04 system is a cutting-edge saturation diving setup designed for operations up to 300 meters of seawater depth. Built to comply with IMCA, DNV, and ASME PVHO-1 standards, ... read more

Owners Asking Price is US $3.2 m on an “as is/ where is basis”. The system would need some refurbishment of around US $750K and in order to classed – it would be an additional cost of approx. US $275K. 80% of the items are new on this system as this Portable SAT Diving System have been operational in 2023. It will take approx. 80-days to refurbish the system but that can be done quicker as well. It is currently located in West Africa. It needs to be noted that this is a 9-man system but can easily be upgraded to a 12-man system with easy if another chamber is added on. The s... read more

This 50-ton Active Heave Compensation (AHC) 2023-built crane is designed for challenging offshore operations with excellent lifting capacity and stability. Fully certified and third-party approved, the crane meets APl-2C standards (6th edition), ensuring it meets the strict requirements for offshore pedestal-mounted cranes. With a maximum lifting capacity of 50 tons and easy operation at a 13m radius on deck and 20m radius internally or subsea. The crane features 95% Active Heave Compensation, significantly minimizing wave-induced motions for smooth and safe operations even in rough sea con... read more

General Data CRANE TYPE Electro-Hydraulic Knuckle-Boom Offshore Crane - DKF1250 ENVIRONMENT High humidity High salinity Crane designed to operate from -20°C to +45°C Ship heel up to 5° Ship trim up to 2° AREA Crane is designed for safe zone CERTIFICATION DNV certificate for entire crane DESIGN RULES DNV 2.22 Lifting Appliances Norsok R-002 EN 13852-1:2004 DNV OSS-308 FEM CLASS. Appliance groups: A4 - Q2 - U4 Mechanical Data HOISTING Main Hoist Max Outreach 35 m Min Outreach 6 m SWL 1 20 ton Outreach 35 m Number of fall 1 Hook Speed (SWL) 0 – 30 m/min Hook Speed (Empty) 0 –... read more
