Description

CLASS NOTE:CCS CSA,CSM, GREATER COASTAL SERVICE RESTRICTION, RO-RO PASSENGER B, AUT-0
BUILDER: INCAT TASMANIA PTY LTD. AUSTRALIA
YEAR OF BUILD:2002
PASSENGER: 780
CARS: 267
GROSS TONNAGE: 6556
NET TONNAGE: 2497
DWT: 721
LENGTH OVERALL: 97.22M
LENGTH BP: 82.8M
BREADTH: 26.16M
DEPTH: 4.57M
DRAFT: 3.43M
HULL TYPE: SINGLE HULL
HULL MATERIAL: ALUMINIUM ALLOY
HULL CONNECTIONS: WELDED
DECKS: 2 DKS;
LANES: 380M X 3.10M X 4.35M (LXWXH)
RAMPS: 1 AFT
4 OIL ENGINES REDUCTION GEARED TO SCREW SHAFTS DRIVING 4 WATER JETS TOTAL POWER: MCR 28,316KW (38,500HP)

MAIN ENGINE:
DESIGN: RUSTON (GROUP: MAN-B&W)
ENGINE BUILDER: PAXMAN DIESELS LTD. - COLCHESTER 4 X 20RK270, 4 STROKE, SINGLE ACTING, VEE 20 CY. 270 X 305, MCR: 7,079 KW (9,625 HP) AT 1,030 RPM
SPEED : 43 KNOTS
LOA 97.22 m
Beam 26.16 m
Draft 3.42 m

Total passenger capacity 780

2 Decks
total 380 Lane meters
abt. 267 Cars

Built in year 2002
Class : China Classification Society
Flag : China
Gross Tonnage of 6,556 and Nett Tonnage of 2,497

Speed : 38 knots
Engines : 4 x Ruston / Paxman Diesels Ltd 20RK270, 28,316 kw, 1,030 rpm, Propellers 1 Water Jet (Port Side Inner) + 1 Water Jet (Port Side Outer) + 1 Water Jet (Starboard Inner) + 1 Water Jet (Starboard Outer)

Specifications

Engine(s)

4 x 28,316 kw, 1,030 rpm, Ruston / Paxman Diesels Ltd 20RK270,
Propellers: 1 Water Jet (Port Side Inner) + 1 Water Jet (Port Side Outer) + 1 Water Jet (Starboard Inner) + 1 Water Jet (Starboard Outer)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified
