Description

3322LM / 4 DECKS
STERN RAMPS - ONE TO MAIN DECK - ONE TO UPPER DECK and WEATHER DECK.
INTERNAL RAMPS TO All DECKS.
FREE HEIGHTS: LH – 5.55 M. MD - 5.55 M – Upper deck and WD - 4.7 M
DECK STRENGTH: 6 ts/m2 on main deck and TTOP – 3 ts/m2 on UDK and WDK
2x MAN B&W 8L48/60B (9.600 kW each)
2x BOW THRUSTERS - 1.100 kW each.
12 x DRIVERS.
Stabilizers: Fins + Anti healing
Service speed abt 20 knots on abt 62 mt
Scrubber fitted
Next Class renewal Q2 2028
LOA 187.06 m
Beam 26.5 m
Draft 6.8 m

Built in year 2008
Design is : JSC Finnpulp
Class : American Bureau of Shipping
Flag : Portugal (Mar)
Gross Tonnage of 25,609 and Nett Tonnage of 7,682

4 Decks
total 3,322 Lane meters

Total passenger capacity 12

Deadweight : 11,300 metric tonnes
Ice classed 1A

Speed : 20 knots
Engines : 2 x MAN / MAN B&W Diesel AG - GEU 8L48/60B, 19,200 kw, 500 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Volvo Penta 1,110 kw, Bowthruster + No Sternthruster (2 Bow Thwart. CP thruster 1,100kw), Boilers : 1 x Aux Service + 1 x Ex Gas Ecn

Specifications

Engine(s)

2 x 19,200 kw, 500 rpm, Scrubber, MAN / MAN B&W Diesel AG - GEU 8L48/60B,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified
