Description

LOA 78 m
Beam 18,6 m
Draft 6,4 m

Built in year 2016
Design is : Focal 522
Class : American Bureau of Shipping
Flag : Malaysia
Gross Tonnage of 3.535 and Nett Tonnage of 1.060

Dynamic Positioning of class : DP 2
Free Deck area about 800m² with a deck strength of 7,5 metric tonnes per square meter
Fire Fighting System of type FiFi 1 installed
Deadweight : 4.151 metric tonnes
Capable of supplies of 1.200m³ Fuel Oils, 200m³ Methanol, 600m³ FW and 800m³ Liquid Mud

Total passenger capacity 60 with 60 berths
11 cabins with 4 berths
4 cabins with 2 berths
8 cabins with 1 berth

Speed : 13 knots
Engines : 2 x Daihatsu / Niigata Engineering Co Ltd Diesel Engines, 4.706 kw, 800 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : Bowthruster (2 Bow)

Specifications

Engine(s)

2 x 4.706 kw, 800 rpm, Daihatsu / Niigata Engineering Co Ltd Diesel Engines,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
