| GRS.OFFSHORE RENEWABLES | |
| Stadthausbruecke 7, Hamburg, Deutschland, 20355, Germany | |
| Contact: | S&P Broker |
| Telephone: | Reveal Telephone Number |
| Telephone: | Reveal Telephone Number |
| Mobile: | Reveal Mobile Phone Number |
| View All GRS.OFFSHORE RENEWABLES Listings | |
| $22,000,000 | | |
| Status: | Available |
| Location: |
Hamburg Hamburg Germany [View Map] |
| Reference: | #1065061 |
Description
LOA 85,65 m
Beam 19,7 m
Draft 6,18 m
Built in year 2006
Design is : MT 6000 Mk II
Class : DNV
Flag : Cyprus
Gross Tonnage of 3.337 and Nett Tonnage of 1.216
Dynamic Positioning of class : DP 2
Free Deck area about 941m² with a deck strength of 5 metric tonnes per square meter
2 Cranes / Gears installed with a max lifting capacity of 3 tons
Deadweight : 4.349 metric tonnes
Capable of supplies of 1.344m³ Fuel Oils, 810m³ FW, 653m³ Liquid Mud and 647m³ Brine
Total 24 berths
12 cabins with 1 berth
6 cabins with 2 berths
Speed : 16 knots
Engines : 4 x Wartsila / Wartsila Finland Oy 9L20, 6.660 kw, 1.000 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (1 Bow Retract. dir. thruster 880kw + 1 Bow Tunnel thruster 880kw)
Specifications
| Builder: | KLEVEN VERFT AS - ULSTEINVIK |
| Constructed: | 2006 |
| Berths: | 24 |
| No. of engines: | 4 |
| Engine power: | 8930 |
| Cruising Speed: | 16. knots |
| Length over all: | 85.65m |
| Beam: | 19.7m |
| Maximum draft: | 6.18m |
| Water capacity: | 810.0 Cubic Metres |
Engine(s)
4 x 6.660 kw, 1.000 rpm, Wartsila / Wartsila Finland Oy 9L20,
Propellers: 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Certification
REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified
MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
Disclaimer
GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
