Description

LOA 78,7 m
Beam 16 m
Draft 5,8 m

Built in year 2013
Design is : UT 755-CDL
Class : American Bureau of Shipping
Flag : Panama
Gross Tonnage of 2.644 and Nett Tonnage of 985

Dynamic Positioning of class : DP 2
Free Deck area about 670m² with a deck strength of 5 metric tonnes per square meter
Fire Fighting System of type FiFi 1 installed
1 KNB installed with a max lifting capacity of 5 tons
Deadweight : 3.200 metric tonnes
Capable of supplies of 887m³ Fuel Oils, 135m³ Methanol, 697m³ FW and 820m³ Brine

Total passenger capacity 26 with 26 berths
8 cabins with 1 berth
9 cabins with 2 berths

Speed : 13 knots
Engines : 2 x Rolls Royce / Rolls Royce Azimuthing Thruster, 1.470 kw, 2.100 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : Bowthruster (2 Bow Tunnel thruster 700kw)

Specifications

Engine(s)

2 x 1.470 kw, 2.100 rpm, Rolls Royce Azimuthing Thruster,
Propellers: 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
