Description

LOA 85 m
Beam 20 m
Draft 7.16 m

Built in year 2010
Design is : VS 485
Class : DNV
Flag : Norway (NIS)
Gross Tonnage of 4,366 and Nett Tonnage of 1,813

Dynamic Positioning of class : DP 2
Free Deck area about 1,005m² with a deck strength of 10 metric tonnes per square meter
Fire Fighting System of type FiFi 2 installed
1 Crane / Gear installed with a max lifting capacity of 3 tons
Deadweight : 4,900 metric tonnes
Ice classed 1C
Capable of supplies of 903m³ Fuel Oils, 146m³ Methanol, 1,007m³ FW, 703m³ Liquid Mud and 418m³ Brine

Total passenger capacity 23 with 23 berths

Speed : 12.5 knots
Engines : 4 x Caterpillar / Caterpillar Inc 3516B, 6,564 kw, 1,600 rpm, Propellers 1 Z Type (Port Side) + 1 Z Type (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (1 Bow Retract. dir. thruster 800kw + 2 Bow Tunnel thruster 1,000kw)

Specifications

Engine(s)

4 x 6,564 kw, 1,600 rpm, Caterpillar / Caterpillar Inc 3516B,
Propellers: 1 Z Type (Port Side) + 1 Z Type (Starboard)
