Description

LOA 64,3 m
Beam 15 m
Draft 5,71 m
Bollard Pull : 76 tons

Dynamic Positioning of class : DP 2
Fire Fighting System installed
1 Crane / Gear installed with a max lifting capacity of 15 tons

Built in year 2002
Design is : UT 738
Class : DNV
Flag : Singapore
Gross Tonnage of 1.864 and Nett Tonnage of 560

Deadweight : 2.000 metric tonnes

Speed : 12 knots
Engines : 2 x Bergens / Rolls-Royce Marine AS BRM-6, 5.296 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar, Bowthruster + Sternthruster (2 Bow Thwart. FP thruster 515kw + 1 Stern Thwart. FP thruster 515kw)

Specifications

Engine(s)

2 x 5.296 kw, 750 rpm, Bergens / Rolls-Royce Marine AS BRM-6,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
