Description

LOA 63,4 m
Beam 15,8 m
Draft 4,8 m
Bollard Pull : 84 tons

Dynamic Positioning of class : DP 1
Free Deck area about 420m² with a deck strength of 5 metric tonnes per square meter
Capable of supplies of 804m³ Fuel Oils, 484m³ FW, 410m³ Liquid Mud and 410m³ Brine
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 3 tons

Built in year 2010
Design is : Seatech P-729
Class : American Bureau of Shipping
Flag : Marshall Islands
Gross Tonnage of 1.943 and Nett Tonnage of 583

Deadweight : 1.272 metric tonnes

Total passenger capacity 28 with 28 berths

Speed : 10,5 knots
Engines : 2 x Yanmar / Yanmar Diesel Engine Co Ltd 8N280-EN, 5.002 kw, 720 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 4 Caterpillar 425 kw, Bowthruster + No Sternthruster (1 Bow Tunnel thruster 500kw)

Specifications

Engine(s)

2 x 5.002 kw, 720 rpm, Yanmar / Yanmar Diesel Engine Co Ltd 8N280-EN,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
