Description

LOA 63,4 m
Beam 15,8 m
Draft 5,1 m
Bollard Pull : 90 tons

Free Deck area about 420m²
Capable of supplies of 804m³ Fuel Oils, 483m³ FW, 410m³ Liquid Mud and 410m³ Brine
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 3 tons

Built in year 2007
Design is : Seatech P-729
Class : Bureau Veritas
Flag : Panama
Gross Tonnage of 1.943 and Nett Tonnage of 650

Deadweight : 1.575 metric tonnes

Total passenger capacity 32

Speed : 10,5 knots
Engines : 2 x Bergens / Rolls-Royce Marine AS C25:33L8P, 4.800 kw, 1.000 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 3 Caterpillar 472 kw, Bowthruster + No Sternthruster (1 Bow Thwart. CP thruster 550kw)

Specifications

Engine(s)

2 x 4.800 kw, 1.000 rpm, Bergens / Rolls-Royce Marine AS C25:33L8P,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
