Description

LOA 60 m
Beam 16 m
Draft 4,85 m
Bollard Pull : 77 tons

Dynamic Positioning of class : DP 1
Free Deck area about 390m² with a deck strength of 5 metric tonnes per square meter
Capable of supplies of 530m³ Fuel Oils, 480m³ FW and 100m³ Dry bulk
Fire Fighting System of type FiFi 1 installed

Built in year 2010
Design is : Conan Wu 60m
Class : China Corporation Register
Flag : Taiwan
Gross Tonnage of 1.706 and Nett Tonnage of 511

Deadweight : 1.798 metric tonnes

Total 26 berths

Speed : 12 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3606, 4.060 kw, 1.000 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (1 Bow Tunnel thruster 600kw)

Specifications

Engine(s)

2 x 4.060 kw, 1.000 rpm, Caterpillar / Caterpillar Inc 3606,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
