Description

LOA 64,8 m
Beam 16 m
Draft 4,92 m
Bollard Pull : 85 tons

Dynamic Positioning of class : DP 1
Free Deck area about 420m² with a deck strength of 5 metric tonnes per square meter
Capable of supplies of 600m³ Fuel Oils and 445m³ FW
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 1,7 tons

Built in year 2007
Design is : Conan Wu 64.8m
Class : Nippon Kaiji Kyokai
Flag : Panama
Gross Tonnage of 1.966 and Nett Tonnage of 590

Deadweight : 1.500 metric tonnes

6 cabins with 1 berth
5 cabins with 2 berths
3 cabins with 4 berths

Speed : 14 knots
Engines : 2 x MaK / Caterpillar Motoren 8M25, 5.280 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 400 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 500kw + 1 Stern Tunnel thruster 500kw)

Specifications

Engine(s)

2 x 5.280 kw, 750 rpm, MaK / Caterpillar Motoren 8M25,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
