Description

LOA 78 m
Beam 18 m
Draft 6 m
Bollard Pull : 151 tons

Free Deck area about 462m² with a deck strength of 5 metric tonnes per square meter
Fire Fighting System of type FiFi 1 installed

Built in year 2012
Class : China Classification Society
Flag : China
Gross Tonnage of 3.214 and Nett Tonnage of 964

Deadweight : 3.520 metric tonnes
Ice classed 1B

Total 30 berths

Speed : 15 knots
Engines : 4 x Guangzhou / Guangzhou Diesel Engine 8320ZC, 8.824 kw, 525 rpm, Propellers 1 x Port Side + 1 x Starboard

Specifications

Engine(s)

4 x 8.824 kw, 525 rpm, Guangzhou / Guangzhou Diesel Engine 8320ZC,
Propellers: 1 x Port Side + 1 x Starboard

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
