Description

LOA 58,7 m
Beam 14,6 m
Draft 4,75 m

Built in year 2009
Design is : KCM-58.7M
Class : Bureau Veritas
Flag : Marshall Islands
Gross Tonnage of 1.527 and Nett Tonnage of 458

Deadweight : 1.368 metric tonnes
Bollard Pull : 52 tons
Free Deck area about 350m² with a deck strength of 7 metric tonnes per square meter
4-Point installed
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 13,5 tons

Total 64 berths

Speed : 13,5 knots
Engines : 2 x Cummins / Cummins Engine Co Ltd QSK60-M, 2.960 kw, 1.800 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (1 Bow Tunnel thruster 419kw)

1 Deck

Specifications

Engine(s)

2 x 2.960 kw, 1.800 rpm, Cummins / Cummins Engine Co Ltd QSK60-M,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
