Description

Use Case:
Cable lay
Remotely Operated Vehicle (ROV)
support and maintenance
CPT/ Vibrocore campaigns
Cable burial and remedial burial
Seismic support
Geotechnical activities
Backfilling of trenches in shallow waters
Implementation of survey activities
Assistance during port operations and
offshore wind farm construction
Dredging activities
Anchor handling
LOA 35,36 m
Beam 10,34 m
Draft 1,4 m

Built in year 1958
Class : Polski Rejestr Statkow
Flag : Saint Kitts-Nevis
Gross Tonnage of 359 and Nett Tonnage of 107

Deadweight : 463 metric tonnes
Bollard Pull : 6 tons
Free Deck area about 150m² with a deck strength of 5 metric tonnes per square meter
4-Point installed
1 Crane / Gear installed with a max lifting capacity of 29,7 tons
1 Crane / Gear installed
1 AF installed

Total passenger capacity 6 with 6 berths
2 cabins with 1 berth
2 cabins with 2 berths

Speed : 6 knots
Engines : 4 x Mitsubishi / Mitsubishi Heavy Industries S6N-MPTA, 956 kw, 1.625 rpm, Propellers 1 Directional (Port Side Fore) + 1 Directional (Port Side Aft) + 1 Directional (Starboard Fore) + 1 Directional (Starboard Aft)
Auxiliaries Engines : 1 x 290 kva + 1 x 51 kva + 1 x 111 kva

Capable of supplies of 136m³ Fuel Oils and 25m³ FW

Specifications

Engine(s)

4 x 956 kw, 1.625 rpm, Mitsubishi / Mitsubishi Heavy Industries S6N-MPTA,
Propellers: 1 Directional (Port Side Fore) + 1 Directional (Port Side Aft) + 1 Directional (Starboard Fore) + 1 Directional (Starboard Aft)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
