| GRS.OFFSHORE RENEWABLES | |
| Stadthausbruecke 7, Hamburg, Deutschland, 20355, Germany | |
| Contact: | S&P Broker |
| Telephone: | Reveal Telephone Number |
| Telephone: | Reveal Telephone Number |
| Mobile: | Reveal Mobile Phone Number |
| View All GRS.OFFSHORE RENEWABLES Listings | |
Description
LOA 130 m
Beam 28 m
Draft 8,8 m
Built in year 2024
Design is : VS 4220 OCV
Class : DNV
Flag : Canada
Gross Tonnage of 15.000 and Nett Tonnage of 4.249
Dynamic Positioning of class : DP 3
Free Deck area about 2.000m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
1 Crane / Gear installed with a max lifting capacity of 250 tons
1 Crane / Gear installed with a max lifting capacity of 35 tons
Deadweight : 10.000 metric tonnes
Ice classed 1C
Capable of supplies of 3.000m³ Fuel Oils and 890m³ FW
Total 100 berths
Speed : 16 knots
Engines : 4 x Wartsila / Unknown Builder, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard) + 1 Azimuth Elec. Dr. (Center)
Auxiliaries Engines : Bowthruster + Sternthruster (2 Bow Tunnel thruster + 1 Bow Retract. dir. thruster + 3 Stern)
Specifications
| Builder: | DAVIE CANADA CHANTIER INC |
| Constructed: | 2024 |
| Berths: | 100 |
| No. of engines: | 4 |
| Cruising Speed: | 16. knots |
| Length over all: | 130m |
| Beam: | 28m |
| Maximum draft: | 8.8m |
| Water capacity: | 890.0 Cubic Metres |
Engine(s)
4 x , Wartsila / Unknown Builder,
Propellers: 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard) + 1 Azimuth Elec. Dr. (Center)
Certification
REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified
MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
Disclaimer
GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
Location Map
Note: Indicated location is approximate general area only.
