Description

LOA 73,2 m
Beam 20 m
Draft 7,75 m
Bollard Pull : 165 tons

Dynamic Positioning of class : DP 2
Free Deck area about 600m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 422m³ Fuel Oils, 618m³ FW, 128m³ Liquid Mud and 128m³ Brine
Fire Fighting System of type FiFi 1 installed
2 Cranes / Gears installed with a max lifting capacity of 13 tons
1 Crane / Gear installed with a max lifting capacity of 2 tons

Built in year 2009
Design is : VS 472
Class : American Bureau of Shipping
Flag : Denmark (DIS)
Gross Tonnage of 4.678 and Nett Tonnage of 1.404

Deadweight : 3.500 metric tonnes

Total 30 berths
14 cabins with 1 berth
8 cabins with 2 berths

Speed : 12 knots
Engines : 4 x MAN / MAN Diesel A/S 7L27/38, 10.200 kw, 800 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 MAN-B&W 800 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster 883kw + 2 Stern Tunnel thruster 515kw)

Specifications

Engine(s)

4 x 10.200 kw, 800 rpm, MAN / MAN Diesel A/S 7L27/38,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
