Description

13 TONS SWL UMBILICAL WINCH

Mobile 13 Te SWL Umbilical Winch
Description
Classification Safe Area (Not suitable for oil rig installation)
Type Hydraulically driven winch
Certification/standard Designed in accordance with DNVGL-ST-0378
Dynamic Amplification Factor 1.7
Safe Working Load SWL 13 Tons
Dimensions Length 3200mm, Width 4200mm, Height 2800mm
Weight 20 000 kg
Operating temperature -10°C up to +45°C
Drum Storage capacity 1650m (based on 44,0mm diameter umbilical cable)
Drum configuration Parallel-groove drum shells (LEBUS)
Speed 30m/min
Level-wind Automatic
Slip ring Focal 176, Not included
Controls
Local, remote
Local control
- Pay-in / out
- Level-wind auto/manual
- Level-wind left / right
- Emergency stop
- Remote control switch
- Pay-out length Reset
- HPU running (indication)
- System Fault (indication)
- Pay-out length (indication)

Remote control
- Pay-in / out
- Emergency stop
- Pay-out length Reset
- Pay-out length (indication)
LOA 11,6 m
Beam 6 m

Specifications

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
